Qualmark OVTTTM 18


Qualmark OVTTTM 18

OVTT is a compact, stand alone omnidirectional vibrating system; allows you to perform repetitive shock vibration tests.

OVTT employs Qualmark's patented 6-degree-of-freedom vibration technology.

The system can be easily configured to be placed inside a climatic chamber for combined temperature / humidity stress screening tests.

The test system is innovative as it allows to simulate conditions that exceed those of normal operation.


Features and performance

  • Control system: integrated Allen - Bradley PLC
  • Workspace (L x W x H): 508 x 508 x 242 mm
  • Acceleration: 5 - 40 grms
  • Actuators: 4
  • Table dimensions: 457 x 457 mm
  • Table load: 23 kg (recommended) - 45 kg (maximum)
